USER INTERFACE/PROGRAMMING MODES
The operating modes of the C48C are programmed using the front panel
keypad. To enter the programming menu, the " key is pushed and held for 2
seconds. Within the programming menu, the " key is used to sequence through
the list of programming parameters.
PROGRAMMING MENU
Program Security/Operator Accessible Values
The Program Disable DIP switch, programmable code value, User Input
(programmed for Program Disable), and the Accessible Value parameters
provide various levels of security against unauthorized programming changes.
The accessible values parameters provide individual access or locking of each
value.
Protected Value Menu
The Protected Value Menu allows access to selected presets, prescaler and
timed output values without having them viewable or changeable from the main
display. To enter the protected menu, the
"
key is pressed and held, and a
programmed code value is entered.
Programming Numeric Data Values
The Presets may be accessible when the unit is in its operating mode.
Pressing the " key will sequence the secondary display through the available
preset, prescaler and Batch/Total count values.
To change a data value it must be visible on the secondary display. Pressing
the $ or # key will allow changing of the value. If the data entry method has
been set to “digit entry”, pressing the $ key multiple times will select other
digits. Pressing the # key will increment the selected digit. If the data entry
method is set to “Auto scrolling”, the data value can be changed by pressing and
holding the # or $ keys to change one or all digits of the display.The data
value will be entered when the " key is pushed, or the old value will be
retained if no key activity is detected for 10 seconds.
Count Input Modes - Cnt In
This parameter controls the count/control function of Inputs A and B. It also
allows Input B to be used as a User Input with the same programmable
functions as the dedicated User Inputs.
* These are the only count input modes available on the Prescaler Output
Model.
Programmable Operating Modes - OPEr
These modes determine the operational characteristics of the counter. In the
tables, 01, 02, and 03, refer to Outputs 1,2, and 3 respectively.
1 - Manual Reset to Zero, Latched Output
2 - Manual Reset to Zero, Timed Output
3 - Manual Reset to Preset, Latched Output
4 - Manual Reset to Preset, Timed Output
5 - Auto Reset to Zero, Timed Output
6 - Auto Reset to Preset, Timed Output
7 - Auto Reset to Zero at Timed Output End
8 - Auto Reset to Preset at Timed Output End
SINGLE PRESET OPERATING MODES
Auto Reset to Preset 3 at 03 Timed Output End - 8
Auto Reset to Preset 3, 03 Timed - 7
Auto Reset to Zero at 03 Timed Output End - 6
Auto Reset to Zero, 03 Timed - 5
Manual Reset to Preset 3, 03 Timed
COUNTER 2 OPERATING MODES (C48CB Only)
- 4
Manual Reset to Preset 3, 03 Latched - 3
Manual Reset to Zero, 03 Timed - 2
Manual Reset to Zero, 03 Latched - 1
Auto Reset to Preset 2 at 02 End, 01 off at 02, 02 Timed
Auto Reset to Zero at 02 End, 01 off at 02, 02 Timed
Manual Reset to Preset 2, 01 and 02 Timed
-
-
-
18
16
8
Auto Reset to Preset 2 at 02 End, 01 and 02 Timed
Auto Reset to Zero at 02 End, 01 and 02 Timed
Manual Reset to Preset 2, 01 Timed, 02 Latched
-
-
-
17
15
7
Auto Reset to Preset 2, 01 off at 02, 02 Timed
Manual Reset to Preset 2, Latched Outputs
-
-
14
6
Auto Reset to Preset 2, 01 and 02 Timed
Manual Reset to Zero, 01 off at 02, 02 Timed
-
-
13
5
Auto Reset to Zero, 01 off at 02, 02 Timed
Manual Reset to Zero, 01 off at 02, 02 Latched
-
-
12
4
Auto Reset to Zero, 01 and 02 Timed
Manual Reset to Zero, 01 and 02 Timed
-
-
11
3
Manual Reset to Preset 2, 01 off at 02, 02 Timed
Manual Reset to Zero, 01 Timed, 02 Latched
-
-
10
2
Manual Reset to Preset 2, 01 off at 02, 02 Latched
Manual Reset to Zero, Latched Outputs
-
-
9
1
DUAL PRESET AND BATCH COUNTER 1 OPERATING MODES
MODE INPUT A INPUT B
C1-USr Count User Input *
C2-USr Count (X2) User Input
C1-Ud Count Up/Dn Control *
C2-Ud Count (X2) Up/Dn Control
Ad-Sub Add Count Subtract Count
Ad-Ad Add Count Add Count
qUAd 1 Quad X1 Inputs
qUAd 2 Quad X2 Inputs
qUAd 4 Quad X4 Inputs
Ac PSc - Accessibility of Prescaler Value
PScALr - Prescaler Value
dEc Pt - Decimal Point Position
Cnt In - Count Input Modes
OPEr 1 - Counter 1 Operating Mode
C2 ASn - Counter 2 Assignment (C48CB only)
OPEr 2 - Counter 2 Operating Mode (C48CB only)
Ac PrS - Accessibility of Preset Values
PrESEt - Preset 1, 2, and 3 Values
PltrAC - P1 Track P2 (not available on C48CS)
Ac Out - Accessibility of Output Time Values
OutPut - Output 1, 2, and 3 Time Values
rEVAnu - Reverse Output Annunciator Logic
rEVOut - Reverse Output/Relay Logic
OutP.uP - Power Up Output State
USrIn1 - User Input 1
USrIn2 - User Input 2 (Not available on Batch Relay Models)
USrInb - User Input b
USr F1 - User F1 Key
CodE - Programming/Protected Parameter menu Code
ScroLL - Scroll Display
SErSEt - Serial Baud Rate & Parity Settings
SErAdr - Serial Unit Address
SErAbr - Abbreviate Serial Mnemonics
PrnOPt - Print Options
PrnrSt - Print & Reset Count Value
PScOAt - Prescaler Output Pulse (C48CP only)
PScLEn - Prescaler Output Pulse Length {width} (C48CP only)
FAcSEt - Load Factory Default Settings
OutrES - Output Resolution
EntrY - Digit or Auto Scrolling Data Entry Mode
(RS485 option only)
