User's Guide ______________________________________________________________________
28 ___________________________________________________________________M210983EN-A
Menus and Functions
The table below shows the menu structure of the MI70 Indicator. The
functions available under some entries, such as the Environment menu,
depend on the connected devices.
Table 5 Menu Structure of the MI70 Indicator
Main Menu First level submenu Functions in the submenu
Display Quantities and units Select measured quantities and units.
Rounding Turn the rounding of measured values ON/OFF
Hold/Save display Hold and save current readings
Graphic history Show history graphs
Functions Alarm Configure the alarm function of the MI70 indicator
Analog output Configure the analog output function of the MI70 indicator
Chemical purge Start the chemical purge function
Calibrate transmitters Start the calibration function for compatible transmitters
Recording/
Viewing Record data Start and stop data recording
View recorded data View recorded files
Memory status Show memory usage
Clear data memory Clear all recorded files
Environment (Available settings
depend on connected
devices) Set environment settings for measurement compensation.
When HMP155 is connected, pressure compensation for
RH measurement can be set.
Settings User interface Configure user interface settings of the MI70 indicator
Date and time Set date, date format, time, and clock type (12h or 24h)
Measurement settings Set measurement settings; available settings depend on
connected devices. When PTB330 is connected, you can
set measurement settings for HCP, QFE and QNH
quantities, measurement averanging filter, and pressure
stability.
Note: the pressure stability setting (P stab) controls the
"OK" indication on the display of the PTB330 barometer. It is
not used in the PTB330TS, so you can ignore the "P stab"
setting.
Device information View device information
Factory settings Revert the MI70 indicator to factory settings
