Figure 7, Mi70 indicator – Vaisala PTB330TS User Manual
Page 27
Chapter 3 ________________________________________________________________ Operation
VAISALA_______________________________________________________________________ 25
0704-035
Figure 7
MI70 Indicator
NOTE
The MI70 indicator is also used in other Vaisala products, such as the
Vaisala HUMICAP Hand-Held Humidity and Temperature Meter
HM70. Because of this, the MI70 indicator has some software features
and accessories that are not relevant for the PTB330TS, and are not
described in this manual.
Numbers refer to
1
=
Recharger connection
2
=
Power button
3
=
Connection ports (2) for cables
