7RS RI 'DVKERDUG 0RXQWLQJ 2SWLRQV
Instructions for Using Velcro ® :
Apply the two adhesive-backed Velcro loop tapes to the flats on the back of
the console or to the back of the bracket.
! Attach the hook tapes to the loop tapes, then press adhesive backing of the
hook tape onto your selected mounting surface.
I‚‡r) Do not separate the Velcro for at least 24 hours after applying.
6XQ 9LVRU 0RXQWLQJ
Use the visor clip to mount your console on a visor or door pocket.
Install the clip on the top or bottom of the console to orient the console as
you wish.
! Push the clip in until the 3rd bump engages.
Pan Head Self-Tapping Screw
Split-Lock Washer
Flat Washer
Hex Nut
Split-Lock Washer
Flat Washer
Right Angle
Adapter Bracket
Mounting Bracket
Flat Head Machine Screw
Bracket Mounting
Loops
Hooks
Velcro Mounting
3 Bumps
(to hold clip)
OR
Visor Clip
