Fan-aspirated iss specifications – DAVIS Vantage Pro ISS Fan-Aspirated Add., 2003 & later User Manual

Page 16

Product Numbers: 6151, 6151C, 6161, 6161C
Davis Instruments Part Number: 7395.152
Integrated Sensor Suite with Fan-Aspirated Radiation Shield Addendum, Rev B
Rev B. Manual (10 June 2002)

The term “IC:” before the radio certification number only signifies that Industry of Canada technical specifica-
tions were met.

3465 Diablo Avenue, Hayward, CA 94545-2778 U.S.A.

510-732-9229 • Fax: 510-732-9188

E-mail: [email protected] • www.davisnet.com

FCC Part 15 Class B Registration Warning

This equipment has been tested and found to comply with the limits for a class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protec-
tion against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications not expressly approved in writing by Davis Instruments may void
the user's authority to operate this equipment.

Fan-Aspirated ISS Specifications

Aspiration Rate . . . . . . . . . . . . . . . . . . . . . 215 ft./min. (1.1 m/s) (AC-powered)

190 ft./min (.96 m/s) (solar-powered, full
sun),

80 feet/min. (0.4 m/s) (battery only)

Radiation-Induced Temperature Error . . . . 0.5°F (0.3°C)

[At solar noon, insolation = 1040 W/m2]
(Reference: RM Young model 43408)

Operating Temperature . . . . . . . . . . . . . . –40° to +140° F (–40° to +60° C)
Non-operating Temperature . . . . . . . . . . . –50° to +158° F (–45° to +70° C)
ISS Primary Power Input
Wireless ISS . . . . . . . . . . . . . . . . . . . . . . solar panel
Cabled ISS . . . . . . . . . . . . . . . . . . . . . . . . receives power from Vantage Pro

Console

ISS secondary power (Wireless Only) . . . . CR-123A 3-volt lithium battery (approx.

two years battery life.)

Fan Primary Power Input
Wireless ISS . . . . . . . . . . . . . . . . . . . . . . . solar panel
Cabled ISS . . . . . . . . . . . . . . . . . . . . . . . . AC power adapter, 5VDC, 200 mA,

regulated

Fan secondary power (Wireless Only) . . . . 1 or 2 - 1.2 Volt NiCad C-cells

ISS Fan Rev B.fm Page 16 Thursday, November 14, 2002 4:29 PM
