DAVIS Vantage Pro ISS Fan-Aspirated Add., 2003 & later - Manual

Product # 6151, 6151C, 6161, 6161C
I N T E G R A T E D S E N S O R S U I T E
W I T H
F A N - A S P I R A T E D
R A D I A T I O N S H I E L D
A
D D E N D U M
, R
E V
B
For Vantage Pro
®
and Vantage Pro Plus™
The Vantage Pro Integrated Sensor Suite (ISS) with the Fan-Aspirated Radia-
tion Shield uses a combination of fan-aspiration and shielding to minimize the
effects of solar radiation-induced temperature error.
Fan-Aspirated ISS Addendum Overview
This addendum provides additional information specific to the installation and
use of the fan-aspirated radiation shield only, and is intended to be used in con-
junction with the “Integrated Sensor Suite Installation Manual.”
The table below shows the location of the information required to install and
maintain your Fan-Aspirated ISS.
S ECTION /P ROCEDURE I N T HIS
A DDENDUM
I N THE ISS
I NSTALLATION
M ANUAL
Tools for Setup X
Preparing the Anemometer X
Preparing the Rain Collector X
Disassembling the Radiation Shield X
Making Junction Board Connections X
Powering ISS and Testing Communica-
tions X
Powering and Testing the Fan X
Reassembling the Radiation Shield X
Choosing a Site for the ISS X
Mounting the ISS X
Additional Mounting Options X
Fan-Aspirated ISS Options X
Fan-Aspirated ISS Maintenance X
Theory of Operation X
Fan-Aspirated ISS Troubleshooting X
Fan-Aspirated ISS Specifications X
