System Installation
Page 4 Industrial System Installation Manual
2. If you plan to mount the SIM against a wall or other vertical surface, attach the base
to the mounting surface using the #6 x 1” screws. Otherwise skip this step.
Use two screws (as shown below) when attaching to a stud. Use three
screws (as shown below) in any other case. Drill pilot holes using a #36
(.106” or 2.5 mm) drill bit.
A TTACHING TO A W ALL OR V ERTICAL S URFACE
3. If you plan to place the SIM on a horizontal surface, attach one of the adhesive pads to
each of the four raised circles on the underside of the base as shown below.
A TTACHING A DHESIVE P ADS
