DAVIS Envoy8X Long Range Repeater Installation Addendum User Manual
Page 8
6
The legend below describes the antenna types and how they will be represented in a sam-
ple antenna configuration:
Antenna Topology Legend
Antenna Symbol
Antenna Type
Vantage Pro2 or
Vantage Vue
Console
Weather
Envoy or
Envoy8X
Vantage Pro2
Wireless
Repeater
Any
Vantage Pro2
or Vantage Vue
Transmitter
Omni-directional
Long Range
Repeater Antenna
Yagi (Directional)
Long Range
Repeater Antenna
