Repeater Board Contents
The board contained within the repeater enclosure has the following contents:
Transmitter
DIP Switches
Repeater
DIP Switches
Repeater
Test Switch
TX
LED
Status
LED
Battery
Compartment
Solar Power Tab
Receiving
Antenna
Cable
AC Adapter
Transmitting
Antenna
Cable
External
Antenna
Connectors
First In Chain
Jumper
1 2 3 4 5 6 7 8
