DAVIS Envoy8X Long Range Repeater Installation Addendum - Manual (Page 15)

13
Specifications
Complete specifications for all of the Vantage Pro2 weather products as well as the wire-
less repeater are available in the Weather Support section of our website:
http://www.davisnet.com/support/weather/
General
Operating Temperature. . . . . . . . . . . . . . -40 to 150° Fahrenheit (-40 to 65° Celsius)
Non-Operating Temperature . . . . . . . . . . -40 to 150° Fahrenheit (-40 to 65° Celsius)
Current Draw . . . . . . . . . . . . . . . . . . . . . 1.5 mA at 4-6 VDC (average draw when not in
Test Mode)
Batteries . . . . . . . . . . . . . . . . . . . . . . . . . CR 123A 3-volt lithium battery
Battery Life Estimates (with no solar or AC power input):
*Both received directly by the repeater and those IDs repeated from the previous repeater in a chain.
Note: Battery life in excess of two years is expected with normal solar input.
Solar Panel . . . . . . . . . . . . . . . . . . . . . . . 0.5 Watts
Alternate Power . . . . . . . . . . . . . . . . . . . AC power adapter
Housing Material. . . . . . . . . . . . . . . . . . . UV-resistant PVC plastic
Dimensions . . . . . . . . . . . . . . . . . . . . . . . 6.25'' x 2.25” x 7.88'' (159 mm x 57 mm x 200 mm)
Weight. . . . . . . . . . . . . . . . . . . . . . . . . . . 1.188 lb. (.539 kg)
# of IDs*
Estimated Life Expectancy
(Months)
1 4
4 1.5
8 <1
