Hardware Installation

2-14 Avaya Wireless AP-4/5/6 User’s Guide

Figure 2-6. Attach Ethernet Cable and Power Cable

NOTE:
Once attached, the power cable locks into place. To disconnect the
power cable, slide back the black plastic fitting and gently pull the
cable from the connector.

Ethernet Cable

Power Cable
