IEEE Menu. The IEEE submenu is used to configure the Model 9240 for communications over the GPIB. An example of the
menu is shown in Figure 3-9 and the description of the commands, parameters and factory defaults is given in Table 3-4.
R T N
A D D R E S S > 1 3
E M U L A T I O N S C P I
E O S L S T N C R L F
E O S T A L K E R C R L F
E O I O N
S R Q M A S K 0
Figure 3-9. IEEE Menu Display
Table 3-4 IEEE MENU Functions
Function Description
Parameters Defaults
RTN
Returns the instrument to the n/a
previous menu.
ADDRESS
GPIB address assigned to the 0 to 30 n/a
instrument.
EMULATION
GPIB emulation mode. SCPI, 437B, 438A, 4230 SCPI
EOS LSTN
End of string indicator for LF, CR, CRLF, NONE LF
received messages. Where:
LF = Line Feed
CR = Carriage Return
CRLF = Carriage Return
and Line Feed
EOS TALKER
End of string character sent LF, CR, CRLF, NONE LF
with transmitted messages.
EOI
Enables/disables the end or ON, OFF OFF
identify hardware control line.
SRQ MASK
Service request interrupt mask. 0 to 255 0
See Section 5.5.1 *STB? for bit Where:
descriptions. 255 enables all interrupts
