Boonton 9240 Series RF Voltmeter
3.3.1 Menu Key.
The instrument's, CHANNELS, SETUP, REPORT and DIAGNOSTIC functions are accessed when the
Channel Menu. An example of the display for the Channels menu is shown in Figure 3-7. Although the figure shows twelve lines, the instrument can only display four at a time. Therefore, it will be necessary to use the up/down arrow keys to sequence through the commands. When viewing the commands, the instrument will retain the first line as a header and use the next three lines to scroll through the remaining commands. Table 3-2 gives a description of the commands available from the Channels menu. The associated parameters, and factory default settings are also given. Setup Menu. An example of the display for the Setup menu is shown in Figure 3-8. It will be necessary to use the up/down arrow keys to sequence through the commands since there are more than four lines of information to be displayed. When sequencing through the commands, the instrument will retain the first line as a header and use the next three lines to scroll through the command list.
R T N
C H A N N E L S
<
S E T U P
R E P O R T
D I A G N O S T I C S
Figure 3-6. Main Menu Display
R T N C H # V O L T
U N I T S > V O L T S
R E S X X X X X B
A
R O
N
M
O
D
E
R A N G E A U T O
A L A R M O F F H I L I M I T 9 9 . 9 9
L O L I M I T - 9 9 . 9 9 Z 0 5 0 . 0 0 P E A K O F F
X 1 0 0 O F F
Figure 3-7. Channels Menu Display
Getting Started
3-9
