Boonton Power Sensor - Manual (Page 4)

Figures
Figure Page
1-1 Error Due to AM Modulation (Diode Sensor) 2
1-2 Linearity Traceability 3
1-3 Calibration Factor Traceability 4
4-1 Model 51071 Low Frequency Response 28
4-2 Model 51072 Low Frequency Response 28
4-3 Model 51075 Low Frequency Response 29
4-4 Model 51071 SWR Data 29
4-5 Model 51072 SWR Data 29
4-6 Model 51075 SWR Data 30
4-7 Model 51078 SWR Data 30
4-8 Model 51100 SWR Data 30
4-9 Model 51101 SWR Data 31
4-10 Model 51102 SWR Data 31
5-1 Pulsed RF Operation 32
5-2 Pulsed Accuracy for Thermocouple Sensors 33
5-3 Pulsed Accuracy for Diode Sensors 34
6-1 Mismatch Uncertainty 39
Tables
Table Page
2-1 Dual Diode and Thermal Sensor Characteristics 5
2-2 Peak Power Sensor Characteristics 9
2-3 Legacy Diode CW Sensor Characteristics 12
2-4 Legacy Waveguide Sensor Characteristics 14
2-5 Legacy Peak Power Sensor Characteristics 16
3-1 Diode & Thermocouple Power Sensor Calibration Factor 17
Uncertainty Models 51011(4B), 51011-EMC, 51012(4C),
51013(4E), 51015(5E), 51033(6E)
3-1 Diode & Thermocouple Power Sensor Calibration Factor 18
Uncertainty (con't.) Models 51071, 51072, 51075, 51077,
51078, 51079
3-1 Diode & Thermocouple Power Sensor Calibration Factor 19
Uncertainty (con't.) Models 51071A, 51072A, 51075A,
51077A, 51078A, 51079A
ii Power Sensor Manual
