Boonton Power Sensor User Manual
Page 20
Table 2-4. Legacy Waveguide Sensor Characteristics (con't.)
Model
Frequency
Range
Dynamic
Range
Overload
Rating
Maximum SWR
Drift and Noise
@ 0 dBm
Lowest Range
Impedance
(Ref. Freq.)
(2)
Drift
Noise
RF Connector
CW Power
Frequency
SWR
after 2 hr.
RMS
2 σ
(dBm)
(GHz)
(/hr)
(typical)
WAVEGUIDE SENSORS
51145 (4U)
40
-40
50 mW
40 to 60
1.45
60 pW
15 pW
30 pW
WR-19
to 60 GHz
to +10 dBm
(UG-383/U)
(50 GHz)
51245 (4U)
40
-50
50 mW
40 to 60
1.45
60 pW
15 pW
30 pW
WR-19
to 60 GHz
to +10 dBm
(UG-383/U)
(50 GHz)
51146 (4V)
50
-40
50 mW
50 to 75
1.45
60 pW
15 pW
30 pW
WR-15
to 75 GHz
to +10 dBm
(UG-385/U)
(60 GHz)
51246 (4V)
50
-50
50 mW
50 to 75
1.45
60 pW
15 pW
30 pW
WR-15
to 75 GHz
to +10 dBm
(UG-385/U)
(60 GHz)
51147 (4V)
75
-40
50 mW
75 to 100
1.45
60 pW
15 pW
30 pW
WR-10
to 100 GHz
to +10 dBm
(UG-387/U)
(94 GHz)
51247 (4V)
75
-50
50 mW
75 to 100
1.45
60 pW
15 pW
30 pW
WR-10
to 100 GHz
to +10 dBm
(UG-387/U)
(94 GHz)
NOTES: 1) -40 to +10 dBm Dynamic Range if used with Model 4200A.
2) Uncertainties:
a) Power Linearity Uncertainty at Reference Frequency: +/- 0.5 dB
b) Cal Factor Uncertainty: +/- 0.6 dB
c) Additional Linearity Uncertainty (referred to -10 dBm): +/- 0.01 dB/dB
Power Sensor Manual
