Table 3-2. Peak Power Sensor Calibration Factor Uncertainty (con't.)
Models 56518, 56526, 56540, 56006, 57006
Freq
Model
56518
56526
56540
56006
(1)
57006
(1)
GHz
%
% RSS
%
% RSS
%
% RSS
%
% RSS
%
% RSS
DUAL DIODE PEAK POWER SENSORS
0.5
1.2
0.8
2.3
1.6
2.2
1.5
2.8
1.4
2.8
1.4
1
1.3
0.8
1.7
1.1
1.6
1.1
2.8
1.4
2.8
1.4
2
1.6
1.0
1.9
1.2
1.8
1.2
2.8
1.4
2.8
1.4
3
1.7
1.1
2.0
1.3
2.0
1.3
3.0
1.5
3.0
1.5
4
1.6
1.0
2.0
1.3
2.2
1.5
3.3
1.5
3.3
1.5
5
2.0
1.2
2.1
1.4
2.3
1.6
3.4
1.5
3.4
1.5
6
2.1
1.4
2.2
1.4
2.4
1.7
3.3
1.5
3.3
1.5
7
1.8
1.2
2.2
1.4
2.7
2.0
8
1.9
1.2
2.4
1.6
2.9
2.2
9
2.6
1.8
3.2
2.5
4.1
3.6
10
2.9
2.1
3.3
2.7
4.2
3.8
11
3.7
2.7
3.5
3.0
4.3
4.1
12
3.7
2.8
3.5
3.1
4.3
4.2
13
3.1
2.2
3.7
3.0
4.5
4.2
14
3.4
2.5
3.6
2.8
4.7
4.2
15
3.6
2.6
3.5
2.4
4.9
4.3
16
3.8
2.8
3.7
2.6
5.1
4.4
17
3.6
2.9
4.0
2.9
5.1
4.2
18
3.7
2.6
4.2
3.2
5.2
4.3
19
5.1
4.0
5.9
5.0
20
5.8
4.9
6.2
5.4
21
6.2
5.2
6.3
5.4
22
5.8
4.5
6.1
5.0
23
5.1
3.7
6.1
4.8
24
5.3
3.9
6.3
4.9
25
5.6
4.1
6.0
4.5
26
6.6
5.1
5.8
4.3
26.5
7.6
5.8
6.2
4.4
27
6.7
4.9
28
6.4
4.8
29
6.6
5.0
30
6.7
5.0
31
7.1
5.5
32
7.2
5.6
33
7.2
5.6
34
6.2
4.8
35
5.6
4.3
36
5.2
4.0
37
4.8
4.0
38
5.5
4.5
39
7.0
6.1
40
8.1
7.6
