Boonton Power Sensor - Manual (Page 16)

Table 2-2. Peak Power Sensor Characteristics (con't.)
Model
Frequency Power Overload
Rise Time
Maximum SWR
Drift & Noise
Range Measurement Rating @ 0 dBm
Peak Fast Slow
Impedance High BW CW Peak Power High Low Frequency SWR Peak Power
RF Connector Low BW Int. Trigger CW Power Bandwidth Bandwidth CW Power
(GHz) (dBm) (ns) (ns) (GHz)
DUAL DIODE PEAK POWER SENSORS
Sensors below are for use with model 4500B ONLY.
58318 0.5 to 18 -24 to 20 1W for 1 us < 10 na to 2 1.15 4 uW
50 Ω
-34 to 20 200 mW (@ 0 dBm) to 16 1.28 0.4 uW
N(M) -10 to 20 to 18 1.34
(6) (7)
Sensors below are for use with models 4500B, 4540 or 4540 w/ 1 GHz calibrator model 2530
59318 0.5 to 18 -24 to 20 1W for 1 us < 10 < 10000 to 2 1.15 4 uW
50 Ω
0.05 to 18 -34 to 20 200 mW (@ 0 dBm) (@ 0 dBm) to 16 1.28 0.4 uW
N(M) -10 to 20 to 18 1.34
(6) (7)
59340 0.5 to 40 -24 to 20 1W for 1 us < 10 > 1000 to 4 1.25 4 uW
50 Ω
0.05 to 40 -34 to 20 200 mW (@ 0 dBm) (@ 0 dBm) to 38 1.65 0.4 uW
K(M) -10 to 20 to 40 2.00
(6) (7)
PEAK POWER SENSOR
Sensors below are for use with model 4500B ONLY.
56006 0.5 to 6 -50 to 20 1W for 1 us < 7 na to 6 1.25 10 nW
50 Ω
-60 to 20 200 mW (@ 0 dBm) 1 nW
N(M) -39.9 to 20
(8) (9)
Sensors below are for use with models 4500B, 4540 or 4540 w/ 1 GHz calibrator model 2530
57006 0.5 to 6 -50 to 20 1W for 1 us < 7 < 10000 to 6 1.25 10 nW
50
Ω
-60 to 20 200 mW (@ 0 dBm) (@ 0 dBm) 1 nW
N(M) -39.9 to 20
(8) (9)
NOTES: 6) Shaping Error (Linearity Uncertainty), all levels 2.3%
7) 30 ns minimum Internal Trigger pulse width.
8) Shaping Error (Linearity Uncertainty), all levels 2.3%
9) Minimum Internal Trigger pulse width to be determined.
Power Sensor Manual 11
