OmniSTAR Demodulator Kit Installation Instructions 7
15. Route Power and Data Extension Cable with the GeoSteer
coaxial cables running to the GeoSteer Control Unit.
16. Bundle the cables together every 12” (30cm) using the
cable ties provided. Use a wire cutter to trim.
17. Attach the Power and Data Extension Cable to the
EXPANSION connector of the GeoSteer Main Cable
Harness.
18. Refer to your GeoSteer User Manual for the OmniSTAR
setup instructions.
Note: In order for the OmniSTAR Demodulator to receive a correction signal, a subscription to the OmniSTAR service must
be purchased and the Demodulator must be set to the proper frequency for the region it is operating in. Refer to the GeoSteer
User Manual for instructions on setting the radio frequency. For region frequencies, see reference table below. For
OmniSTAR subscription information, contact your OmniSTAR service representative.
