GS-450 Radio Kit Installation Instructions

602-0307-01 Rev A

200-0667-01 Kit
200-0667-02 Kit
200-0667-03 Kit

GeoSteer GS-450 Radio Kit

Item

Component

Part Number

Qty

Notes

1.

Assembly, Radio GS-450

200-0666-01

1

2.

Cable, RF Radio NMO 10"

201-0537-01

1

3.

Antenna, 406-430 MHz 5DB NGP

Antenna, 430-450 MHz 5 DB NGP

Antenna, 450-470 MHz 5DB NGP

500-0093-02

500-0094-02

500-0095-02

1

Included antenna is specific to each
kit.

4.

Cable, Power and Data Extension

201-0535-01

1

5.

Screw, Pan-head M6 x 25mm SS

515-0120-01

2

6.

Washer, Split Lock M6

517-0031-01

2

7.

Cable Tie, 5-1/2" x 0.13" Black
Nylon

510-0078-01

20

8.

Installation Instructions

602-0307-01

1
