EASY ModE AppliCAtion USE
Easy mode enables you to access basic guidance more quickly. It is the default operation mode.
Reset guidance Configure the implement Select the pattern Map the Ab line Guidance
Select the
icon and then
press o.
Set the implement width,
the overlap/skip, and the
offsets.
See GUIDANCE
PATTERNS.
Drive and define
the guidance line
or headland.
Note - If you select the A+ pattern, you are prompted to enter the heading of the master guidance line. If you
select the Headlands pattern, you are prompted to select the number of headland circuits.
Built-in Help
The lightbar has a built-in help system. To view it, press the button.
Quick Start Wizard
By default, the Quick Start Wizard appears every time you turn on the EZ-Guide 500 lightbar. It enables you to confirm or
change important system settings before you begin working.
To cancel the Quick Start Wizard and go directly to guidance, press
.
Note - On the last screen in the Quick Start Wizard, you can choose to hide the wizard during future startups.
Function (left side)
Icon Description
Display information tabs
Display built-in help
Turns on or off coverage logging
Return to map view
(Menu and wizard screens)
Return to previous menu
(Menu screens)
Cancel changes
(Edit screens)
Go back to previous screen
(Wizard screens)
Go to next screen
(Wizard screens)
Action (right side)
Icon Description
Reset guidance
Nudge guidance line left and
right
Shift to here
(Advanced mode only)
Change zoom level
Pause, and get guidance back
to the pause position
Display panning icons
(Advanced Mode Only)
Display Mapping icons
(Advanced mode only)
Change views
(Advanced mode only)
Go to configuration menu
Field definition (right side)
Icon Description
Set Point A and Point B
Start and finish headland
Pause curve logging (record a
straight line segment)
Next AB Line
Recording FreeForm curve
Not recording FreeForm curve
