KEYPAD
LIGHTBAR DISPLAY BRIGHTNESS
To change the brightness level of the lightbar display, press and hold: .
© 2003.
T
ri
m
b
le
N
a
vi
gat
ion Limit
ed.
Al
l r
ight
s r
e
ser
v ed.
EZ-G
uide is
a
tr
a
dem
ar
k
of
T
rimb
le Na
vigat
ion Li
m
it
ed li
censed t
o
Ag L
eader T
e
chnol
og
y.
P
a
rt
N
u
m
b
e
r
48651-40-ENG
.
Re
v.
A
(J
an
uar
y 2003).
MODE
Select Guidance, Area, or
Configuration modes.
CLEAR AREA
Clear all area points.
ADD AREA POINTS
Add an area point. The new
area is displayed briefly.
RESET GUIDANCE
Reset the guidance in
preparation for a new field.
ENTER
Select a configuration option
or accept a configuration
value.
SHIFT
• Press to access yellow
functions on other keys.
• Press and hold to change
the brightness of the
lightbar display.
• When editing configuration
values, press to toggle
between increasing and
decreasing the values.
–/+
• Increase or decrease
swath number if
SNAPSWTH is off.
• Scroll through
configuration options.
• Increase or decrease
configuration values.
PAUSE/RESUME
Pause or resume guidance.
SET A/SET B
Set the A or B point for
swath guidance.
