The lower area lists the operation history of XP Snapshot pairs.
• Time: Date and time (YYYY/MM/DD hour/min/sec) when a XP Snapshot pair or volume operation
was performed.
• P-Vol: CU and LDEV number of the P-VOL used for XP Snapshot operations.
• S-Vol: CU and LDEV number of the S-VOL used for XP Snapshot operations. When there is no S-
VOL, --- appears.
• MU: ID of snapshot data used for XP Snapshot operations.
• Pool: Pool ID of the pool in which the XP Snapshot pair is registered.
• Code: Reference code for XP Snapshot. For more information about reference codes, see Table
23 on page 72.
• Message: Message indicating the operation or XP Snapshot pair's status. See Table 23 on page 72.
Table 23 XP Snapshot history reference codes and messages
Description Message Code
A XP Snapshot pair was created. PAIR 0x2001
A XP Snapshot pair was split. PSUS 0x2011
A XP Snapshot pair was deleted. SMPL 0x2021
Restoration of a XP Snapshot pair started. COPY(RS-R) START 0x2030
Restoration of a XP Snapshot pair ended normally. COPY(RS-R) END 0x2031
Restoration of a XP Snapshot pair ended abnormally. COPY(RS-R) ENDED ABNORMAL 0x2032
Snapshot data was deleted. COPY(RS) 0x2051
A failure occurred and the XP Snapshot pair's status
changed to PSUE.
PSUE(ABNORMAL END) 0x2070
Initialization started. INITIALIZE START 0x2040
Initialization ended normally. INITIALIZE END 0x2041
Initialization ended abnormally. INITIALIZE ENDED ABNORMAL 0x2042
XP Snapshot operations 72
