About the reset button
The Brocade 4Gb SAN Switch integrates a Reset button, as shown in Figure 9 . The
Reset button is a small, recessed micro–switch that is accessed by inserting a pin (or
object of similar size) in the small hole.
Use the Reset button to reboot the switch.
scale: 1" = 1"
17 18 19 20
!
Reset
25076a
2
1
Figure 9 Locating the Reset button
Table 14 Locating the reset button
Item Description
1 Port side of switch
2 Reset button
Rebooting the switch
Depress the Reset button for up to 5 seconds to reboot the switch.
