scale: 2/3" = 1"
21
22
23
17
18
19
20
!
Reset
25071a
2
3
1
Figure 4 Releasing the installation handle
Table 6 Release mechanism components
Item Description
1 Installation handle in latched position
2 Handle latch
3 Installation handle (released)
3. Align the Brocade 4Gb SAN Switch with the appropriate interconnect bay
according to your enclosure’s specific configuration. Push firmly into the interconnect
bay. See Figure 5 .
Brocade 4Gb SAN Switch for HP c-Class BladeSystem 25
