Checking LEDs
See Figure 6 to locate power-on LEDs. Verify that the LEDs match the indicators
described in Table 7 .
scale: 1" = 1"
17 18 19 20
!
Reset
25075a
1
2
3
Figure 6 Verifying power-on LEDs
Table 7 Power-on LEDs
Item Description Indicators
1 UID LED Off
2 Health ID LED Steady green light
3 Module Status LED Steady green light
Brocade 4Gb SAN Switch for HP c-Class BladeSystem 27
