I/O menu
Items on the I/O (input/output) menu affect the communication between the product and the computer.
If the product contains an HP Jetdirect print server, you can configure basic networking parameters by
using this submenu. You can also configure these and other parameters through HP Web Jetadmin or
the embedded Web server.
For more information on these options, see Connect to a network on page 68 .
To display: Press the Home button , select the CONFIGURE DEVICE menu, and then select the I/
O menu.
NOTE: Values that have an asterisk (*) are the factory-default values. Some menu items have no
default.
Item Sub-item Values Description
I/O TIMEOUT Range: 5 - 300 Allows you to set the product I/O
TIMEOUT in seconds. The default
is 15 seconds.
Use this setting to adjust timeout
for the best performance. If data
from other ports appears in the
middle of your print job, increase
the timeout value.
EMBEDDED JETDIRECT MENU See the next table for a list of options.
Table 2-1 Embedded Jetdirect menu
Item Sub-item Sub-item Sub-item Description
INFORMATION PRINT SEC PAGE YES*
NO
YES: Prints a page that contains the current
security settings on the HP Jetdirect print
server.
NO: A security settings page is not printed.
TCP/IP ENABLE ON*
OFF
ON: Enable the TCP/IP protocol.
OFF: Disable the TCP/IP protocol.
HOST NAME An alphanumeric string, up to 32 characters,
used to identify the product. This name is
listed on the HP Jetdirect configuration page.
The default host name is NPIxxxxxx, where
xxxxxx is the last six digits of the LAN
hardware (MAC) address.
32 Chapter 2 Control panel menus ENWW
