Chapter 4 Running DiagTools in the Text Mode (from the Utility Partition)
20
the screen (and in the list shown below). Use the arrow keys to highlight the type of tests you want
to run.
System
Memory
IDE
FDD (Flexible Disk Drive)
SCSI
KBD (Keyboard)
Video
Misc
Batch
A drop-down menu will display the available individual tests.
Once the Advanced System Tests are displayed, you have the following options:
Run the Highlighted Test(s)
Help
Edit Batch Parameters
Load Batch Parameters
Save Batch Parameters
Select/Deselect a Test
Select/Deselect All Tests in (the Highlighted) Menu
Select/Deselect All Tests
List Function Keys
Run the Selected Tests
Return to Main Menu
1. When the Basic System Tests are completed, you may want to run Advanced System Tests.
To do so, navigate back to the Advanced System Test menu.
If you receive a message while DiagTools initializes, record and report the message to your
support provider. Then press ENTER to proceed.
2. Tests can be run individually or in batches.
NOTE For information about using Batch mode when DiagTools is running, choose
Batch Help on the Batch submenu.
To run any of the tests in the Advanced System Test menu take the following steps:
a. Highlight the item you to be tested on the Main Menu. Then press the F6 function key.
Check marks appear next to all tests in the highlighted menu, indicating that those tests
are selected.
b. Press the F10 function key to start the tests.
c. Repeat these steps to run any of the following tests as needed:
Advanced System Test Menus
System
Memory
