Chapter 3

Running DiagTools in the Graphical Mode (from Diskette)

12

Running the Advanced System Tests

Advanced System Test Menus and Options

The graphical interface of the Advanced System Tests displays a color screen and initializes the various
tests. This may take a few minutes. The Advanced System Tests are listed across the top of the screen (and
in the list shown below). Use the arrow keys to highlight the type of tests you want to run.

System
Memory
IDE
FDD (Flexible Disk Drive)
SCSI
KBD (Keyboard)
Video
Misc
Batch

A drop-down menu will display the available individual tests.

Once the Advanced System Tests are displayed, you have the following options:

Run the Highlighted Test(s)

Help

Edit Batch Parameters

Load Batch Parameters

Save Batch Parameters

Select/Deselect a Test

Select/Deselect All Tests in (the Highlighted) Menu

Select/Deselect All Tests

List Function Keys

Run the Selected Tests

Return to Main Menu

1. When the Basic System Tests are completed, you may want to run Advanced System Tests. To do so,

navigate back to the Advanced System Test menu.

If you receive a message while DiagTools initializes, record and report the message to your support
provider. Then press ENTER to proceed.

2. Tests can be run individually or in batches.

NOTE

For information about using Batch mode when DiagTools is running, choose Batch Help
on the Batch submenu.

To run any of the tests in the Advanced System Test menu take the following steps:

a. To select an individual test, use the arrow keys to highlight that test. Them press F5 to select it.
