Processor Load Balance and Performance Charts
The next major section of the GPA report (Example 4-12 and Example 4-13) contains two
charts that give you a more detailed picture of the system based on the performance of
the system‟s processors. The first chart shows you graphically how the system load is
distributed among the processors. Abnormal conditions such as a memory shortage or
excessive transient processing are also indicated here (by flags following the CPU
numbers).
The load balance chart for \NODEA (Example 4-12) shows the imbalanced condition on
this node but, more importantly, it indicates a severe memory shortage for CPU 0 and
a moderate shortage for CPU 1.
Example 4-12. Processor Load Balance and Performance Charts for \NODEA
CPU PROCESSOR LOAD BALANCE CHART
NUM
--- ROUNDED TO NEAREST TWO PERCENT (2%)
|----+----+---wwww^wwww--+----+----+----+----+----|
0 |+++++----------->^M
1 |++++++++---------^-------------->Q
2 |++++-----------> ^
3 |++---> ^
|----+----+---wwww^wwww--+----+----+----+----+----|
0 1 2 3 4 5 6 7 8 9 1
0 0 0 0 0 0 0 0 0 0
0
CPU PERCENT BUSY -------------------------------->
PROCESSOR PERFORMANCE CHART
CPU NUM : 0 1 2 3
CPU TYPE : TXP TXP TNSII TNSII
MB MEMORY: 8 8 8 8
PCT BUSY : 34.19 66.04 32.71 11.96
DISK PRIME : 4 0 5 0
DISK RATE : 11.9 6.8
CHIT RATE : 14.3 7.8
MSG RATE : 37 21 16 6
DISP RATE : 117.3 111.1 69.7 29.8
SWAP RATE : 1.26 .93 .17
MMGR PAGES : 8 58 513 1475
