• Click the Edit button.
The Edit Configuration dialog box appears.
Table 4 VASA Configuration Edit options
Description Field
Displays the port number used by the VASA service. You can change the Port
number only through the installation process. VASA service TCP port
Indicates that secure communications are implemented. For security purposes, this
option is fixed and cannot be modified. Secure services
Displays the current thumbprint binded to the TCP port. Binded to thumbprint
Specifies the debug level. There are three debug levels to choose from (low, medium,
high). Setting the level to high will log everything including communication request
and responses between SMS and VASA. Debug level
The location of the log folder is fixed. Log folder
Saves the current configuration. Save (button)
Closes the Edit dialog. Close (button)
If the debug level is modified, changes are updated to the VASA web service immediately.
Figure 18 VASA Edit configuration
NOTE: The VASA Provider service uses the StoreServ credentials entered in Storage Administrator
Portal for vCenter for connecting to the Storage array. For more information on entering credentials
in Storage Administrator Portal for vCenter, see the HP Insight Control for VMware vCenter Server
User Guide.
StoreServ Credential tab
The StoreServ Credential tab allows you to add, remove, and validate HP 3PAR StoreServ credentials
associated with a specific Windows login account.
StoreServ Credential tab 43
