DDS-3 Drive Physical Specifications
Figure 1–2 describes the physical specifications of the DDS-3 drive.
150 mm (5.85 in.)
+ + +
60 mm
90 mm
4 mm
21 mm
(0.82 in.) (2.34 in.)
(3.51 in.)
41.3 mm
(1.61 in.)
5 mm
(0.20 in.)
101.6 mm (3.96 in.)
41.3 mm
(1.61 in.)
101.6 mm
(3.96 in.)
+ +
+ +
94 mm
(3.66 in.)
3.8 mm
(.15 in.)
30.9 mm
(1.20 in.)
70 mm
(2.73 in.)
(0.15 in.)
Figure 1–2. HP DDS-3 Drive Physical Specifications
