Vandal-resistant video door station (surface-mount)
(IS-DV)
Power source
Supplied from the central control unit or add-
on control unit
Communication Open voice hands-free communication
Ambient temperature -10 - 60°C (+14°F - +140°F)
Camera 1/4-inch color CMOS
Minimum illumination 5 Lux
Camera angle Wide: Approx. 170° (horizontal)
Mounting Surface-wall mount (directly to wall)
Material
Front panel: Aluminum die-cast
Main unit: Flame resisting PC+ABS resin
Color Front panel: Dull-gray silver
Weight Approx. 520g (1.15 lbs.)
Remarks Weather-resistant
IP vandal-resistant video door station (surface-
mount) (IS-IPDV)
Power source
48V DC (PoE)
24V DC (supplied from the power supply unit)
Consumption
Max. 85mA (PoE)
Max. 160mA (when power supply unit is
used)
Communication Open voice hands-free communication
Ambient temperature -10 - 60°C (+14°F - +140°F)
Camera 1/4-inch color CMOS
Minimum illumination 5 Lux
Camera angle Wide: Approx. 170° (horizontal)
Mounting Surface-wall mount (directly to wall)
Material
Front panel: Aluminum die-cast
Main unit: Flame resisting PC+ABS resin
Color Front panel: Dull-gray silver
Weight Approx. 540g (1.19 lbs.)
Remarks Weather-resistant
Vandal-resistant video door station (fl ush-mount)
(IS-DVF)
Power source
Supplied from the central control unit or add-
on control unit
Communication Open voice hands-free communication
Ambient temperature -10 - 60° C (+14°F - +140°F)
Camera 1/4-inch color CMOS
Minimum illumination 5 Lux
Camera angle Wide: Approx.170° (horizontal)
Mounting Flush-mount
Electrical box Not used (mounts on built-in back box.)
Material
Front panel: Stainless steel
Main unit: Flame resisting PC+ABS resin
Color
Front panel: Stainless steel, vertical hair-line
processed
Back box: Black
Weight
Approx. 810g (1.79 lbs.)
Back box: Approx. 600g (1.32 lbs.)
Remarks Weather-resistant
IP vandal-resistant video door station (fl ush-mount)
(IS-IPDVF)
Power source
48V DC (PoE)
24V DC (supplied from the power supply unit)
Consumption
Max. 85mA (PoE)
Max. 160mA (when power supply unit is used)
Communication Open voice hands-free communication
Ambient temperature -10 - 60° C (+14°F - +140°F)
Camera 1/4-inch color CMOS
Minimum illumination 5 Lux
Camera angle Wide: Approx.170° (horizontal)
Mounting Flush-mount
Electrical box Not used (mounts on built-in back box.)
Material
Front panel: Stainless steel
Main unit: Flame resisting PC+ABS resin
Color
Front panel: Stainless steel, vertical hair-line
processed
Back box: Black
Weight
Approx. 860g (1.90 lbs.)
Back box: Approx. 600g (1.32 lbs.)
Remarks Weather-resistant
Vandal-resistant audio door station (fl ash-mount)
(IS-SS)
Power source
Supplied from the central control unit, add-on
control unit or room sub control unit
Communication Open voice hands-free communication
Ambient temperature -10 - 60°C (+14°F - +140°F)
Mounting Flush-mount
Electrical box Not used (mounts on built-in back box.)
Material
Front panel: Stainless steel
Main unit: Flame resisting PC+ABC resin
Color
Front panel: Stainless steel, vertical hair-line
processed
Back box: Black
Weight
Approx. 820g (1.81 lbs.)
Back box: Approx. 600g (1.32 lbs.)
Remarks Weather-resistant
Room sub station (IS-RS)
Power source
Supplied from the central control unit, add-on
control unit or room sub control unit
Communication
Handset: Simultaneous communication
Hands-free: Auto-voice actuation
Ambient temperature 0 - 40°C (+32°F - +104°F)
Mounting
Surface-wall mount (directly to wall or
electrical box)
Electrical box 1-gang box
Material Flame resisting ABS resin
Color Black
Weight Approx. 530g (1.17 lbs.)
