GETTING STARTED
USING THE SYSTEM
APPENDIX
SETTING AND ADJUSTMENT
SPECIFICATIONS
IP control unit (IS-IPC)
Power source 48V DC (supplied from the power supply unit)
Current consumption Max. 105mA
Ambient temperature 0 - 40°C (+32°F - +104°F)
Talk channels Video
channels, other channels
Standard (IP) system: 2 talk & 2 constrained
video channels, 1 chime, and 1 telephone
(North America only)
Central control unit
Max.1
Room sub control unit
LAN
Ethernet (10 BASE-T, 100 BASE-TX)
Mounting Rack-mount (19-inch, 2U rack) or wall-mount
Material Steel plate
Color Black
Weight Approx. 3.6kg (7.94 lbs.)
Central control unit (IS-CCU)
Power source 48V DC (supplied from the power supply unit)
Current consumption Max. 800mA
Ambient temperature 0 - 40° C (+32°F - +104°F)
Talk channels Video
channels Local system: 2 talk & 2 video channels,
1 chime
Master station(s) Max. 4
Video door station(s)
Max. 4 Audio door station(s)
Room sub station(s)
Add-on control unit
Max. 2
Room sub control unit Max. 4
IP control unit Max. 1
Video output
NTSC
BNC (Video channel 1,2)
LAN Ethernet (10 BASE-T, 100 BASE-TX)
Mounting Rack-mount (19-inch, 2U rack) or wall-mount
Material Steel plate
Color Black
Weight Approx. 4.0kg (8.82 lbs.)
Add-on control unit (IS-SCU)
Power source 48V DC (supplied from the power supply unit)
Current consumption Max. 1.2A
Ambient temperature 0 - 40°C (+32°F - +104°F)
Talk channels Video
channels Local system: 2 talk & 2 video channels,
1 chime
Master station(s) Max. 8
Video door station(s)
Max. 8 Audio door station(s)
Room sub station(s)
Video output
NTSC
BNC (Video channel 1,2)
Mounting Rack-mount (19-inch, 2U rack) or wall-mount
Material Steel plate
Color Black
Weight Approx. 4.0kg (8.82 lbs.)
Room sub control unit (IS-RCU)
Power source 48V DC (supplied from the power supply unit)
Current consumption Max. 1.8A
Ambient temperature 0 - 40° C (+32°F - +104°F)
Talk channels Local system: 2 talk channels, 1 chime
Audio door station(s)
Room sub station(s)
Max. 30
Mounting Rack-mount (19-inch, 2U rack) or wall-mount
Material Steel plate
Color Black
Weight Approx. 4.0kg (8.82 lbs.)
Color monitor master station (IS-MV)
Power source
Supplied from the central control unit or add-
on control unit
Communication
Handset: Simultaneous communication
(When press-to-talk (PTT) is not set)
Hands-free: Auto-voice actuation
or Press-to-talk (PTT)
Ambient temperature 0 - 40°C (+32°F - +104°F)
Monitor 3.5 inch color LCD monitor
Call history
Call record: 20
Reception record: 20
Paging capacity
Simultaneous paging to max. 5 zones and/or
stations, or 1 pilot zone of a remote site
Mounting
Desktop use (with or without desktop stand)
or wall-mount
Electrical box 1 or 3-gang box*
Material Flame resisting ABS resin
Color Black
Weight Approx. 820g (1.81 lbs.)
*: 1-gang box…..For wiring only (Fix the unit to the wall directly)
3-gang box…..For wiring and fi xing the unit
Color monitor IP master station (IS-IPMV)
Power source
48V DC (PoE)
24V DC (supplied from the power supply unit)
Current consumption
Max. 65mA (PoE)
Max. 130mA (when power supply unit is
used)
Communication
Handset: Simultaneous communication
(When press-to-talk (PTT) is not set)
Hands-free: Auto-voice actuation
or Press-to-talk (PTT)
Ambient temperature 0 - 40°C (+32°F - +104°F)
Monitor 3.5 inch color LCD monitor
Call history
Call record: 20
Reception record: 20
Paging capacity
Simultaneous paging to max. 5 zones and/or
stations, or 1 pilot zone of a remote site
Mounting
Desktop use (with or without desktop stand)
or wall-mount
Electrical box 1 or 3-gang box*
Material Flame resisting ABS resin
Color Black
Weight Approx. 820g (1.81 lbs.)
*: 1-gang box…..For wiring only (Fix the unit to the wall directly)
3-gang box…..For wiring and fi xing the unit
