83327100

1192

®

O AlPHONE

" CHIME TONE INTERCOM

Type; 2 doors — 3 rooms

Model;

V

IE-2ADÍU)

(Room master station)

J

INSTRUCTIONS

NAMES AND FUNCTIONS

Handset

Chime tone volume

control

Visitor call LED

Monitoring door station

changeover button

Door release button

Room call button

Mounting accessories;

Screw ( X 2)

(for mounting to

electrical box)

Wood screw ( x 2)

(for mounting to

wall surface)

iH/lOAs/

i

Wall-mounting

bracket

v_

IE-2AD(U)

a

FEATURES

IE-2AD(U) is a Chime Tone Intercom room master station for
system with max. three room stations and max. two door
stations (IE series).

For power supply, a bell transformer can be used for both
communication and door release (Example; when EL-9S is used,
select a bell transformer of AC12 ~ 16V, 450mA or more).

A power supply (DC12 ~ 24V, 200mA or more) may also be used
only for communication.

Video entry security system can be developed, employing

PanTilt video door station (max. 1) and

MY-CL7MYH-CU video monitors (Refer to the MY-CU
Instructions for details).

* Thin and compact body design, matching interior decor.
* 4-stroke or 2-stroke chime and LED illumination for

doorstation call-in.

* Simply pick up handset at any room station to reply to the

caller.

* Transfer of door station call to another room.

1

Door # 1

Door #2

Door release

Instant reply to second door station call and return by
changeover switch.
Door release button on room stations.

Adjustable chime call volume.

Optional call extension speaker.
