OUTLINE OF OPERATIONS
This manual mainly describes the following operations.
Operations you can do within a site (communication, transferring, paging, monitoring, door release, etc.)
•
Operations you can do between sites (communication, transferring, paging, door release, etc.)
•
Telephone operations and other telephone-related operations (North America only)
•
NOTES:
The arrows in the fi gure above show examples of operations.
•
For the available functions and operations in a local system, refer to the “OPERATION MANUAL” for the local system.
•
For operating a PC master station (IS-SOFT), refer to the “OPERATION MANUAL” for the PC master station.
•
You can communicate with the pilot station or page the pilot zone registered in a remote site. You cannot select a desired station or zone in a
•
remote site.
Depending on the system confi guration of a remote site, some operations to the site may be disabled.
•
A call or talk may not be possible when the communication path is fully occupied.
•
Video images at the target video door station may not appear on the monitor when the video path is fully occupied even though a call or talk is
•
possible.
IP
IP
IP
IP
IP
IP
IP
IP
IP
IS-IPC
IS-IPC
IS-CCU
IS-CCU
IS-RCU
IS-RCU IS-RCU IS-SCU
IS-SCU
IS-RCU
IS-IPC
IP
IP
Standard (IP) system
Standard (IP) system
Local system
The pilot station or zone that receives a
call, paging, etc. from a remote site.
Communication,
Communication,
transferring,
transferring,
paging, door
paging, door
release, etc.
release, etc.
Communication,
Communication,
transferring,
transferring,
paging, door
paging, door
release, etc.
release, etc.
: Control offi ce, etc.
Building A
Building B
Building C
Building D
Building E
PSTN / private line (North America only)
Internet / WAN
PBX telephone
PBX telephone
LAN (IP network)
LAN (IP network)
Site 1
Site 2
Site 32
Site 3
Site 4
Telephone
IP unit
Communication,
Communication,
transferring, paging,
transferring, paging,
monitoring, door
monitoring, door
release, etc.
release, etc.
