Specifications and Dimensions
F8138601 36
Steam Requirements
(Steam Heat Option Only) For washer-extractors equipped with optional steam
heat, install piping in accordance with approved
commercial steam practices. Steam requirements are
shown in Table 8.
NOTE: Failure to install the supplied steam filter
may void the warranty. Never touch internal or external steam
pipes, connections, or components. These
surfaces can be extremely hot and will
cause severe burns. The steam must be
turned off and the pipe, connections, and
components allowed to cool before the
pipe can be touched.
SW014
WARNING
Steam Supply Information
35 60 80 100 125/150
Steam inlet connection,
in. (mm)
1/2
(DN13)
1/2
(DN13)
1/2
(DN13)
1/2
(DN13)
3/4
(DN19)
Number of steam inlets 1 1 1 1 1
Recommended pressure,
psi (bar)
30 – 85
(2.0 – 5.9)
30 – 85
(2.0 – 5.9)
30 – 85
(2.0 – 5.9)
30 – 85
(2.0 – 5.9)
30 – 85
(2.0 – 5.9)
Maximum pressure,
psi (bar) 85
(5.9)
85
(5.9)
85
(5.9)
85
(5.9)
85
(5.9)
Table 8
