Specifications and Dimensions
13 F8138601
Machine Foundation Requirements
A 6 inch (153 mm) (for 35 and 60 2-speed, L-speed
and M-speed models) or a 12 inch (305 mm) (for all
other models) thickness of 3500 psi reinforced
concrete foundation is absolutely necessary because of
the high extract speed and the G-forces exerted.
When designing floors or foundations, refer to Table 2
for Floor Load Data for all model sizes. If the
foundation requirements have been met, proceed to
Mounting Bolt Installation Requirements section.
NOTE: Do not mount on wooden floors, above
ground level, or over basements. Installation must
be “slab on grade” or equal.
Thoroughness of detail must be stressed with all
foundation work to ensure a stable unit installation,
eliminating possibilities of excessive vibration during
extract.
For new foundations a bolt-locator fixture or rebar
frame is available and a preferred option. This rigid
welded assembly made of reinforcing rod and
mounting bolts is designed to be embedded in
concrete. Refer to Figure 7.
The washer-extractor must be anchored to a smooth
level surface so that the entire base of the machine is
supported and rests on the mounting surface. (Do not
support the washer-extractor on only four points.)
Make sure to grout machine. Refer to Figure 6 and
Figure 7.
Ensure that the machine is installed on a
floor that is level to within 3/8 inch when
the machine is grouted. Also ensure that
the floor is of sufficient strength and that
the recommended clearances for
inspection and maintenance are provided.
Never allow the inspection and
maintenance space to be blocked.
W760
CAUTION
To reduce the risk of fire, this appliance
must be bolted to an uncovered concrete
floor.
W743
WARNING
