Specifications and Dimensions
15 F8138601
Figure 5
PHM771N
35 60 80 100 125 150
1
2-Speed,
L-Speed and M-Speed
6 in. (153 mm)
12 in.
(305 mm)
12 in.
(305 mm)
12 in.
(305 mm)
12 in.
(305 mm)
Variable-Speed
12 in. (305 mm)
2
6 in.
(152 mm)
minimum
6 in.
(152 mm)
minimum
6 in.
(152 mm)
minimum
6 in.
(152 mm)
minimum
6 in.
(152 mm)
minimum
6 in.
(152 mm)
minimum
3
9 in.
(229 mm)
12 in.
(305 mm)
12 in.
(305 mm)
12 in.
(305 mm)
12 in.
(305 mm)
12 in.
(305 mm)
4
36 in.
(914 mm)
36 in.
(914 mm)
43.75 in.
(1111 mm)
43.75 in.
(1111 mm)
48 in.
(1219 mm)
56 in.
(1422 mm)
5
0 - 8 in.
(0 - 203 mm)
max.
0 - 8 in.
(0 - 203 mm)
max.
0 - 8 in.
(0 - 203 mm)
max.
0 - 8 in.
(0 - 203 mm)
max.
0 - 8 in.
(0 - 203 mm)
max.
0 - 8 in.
(0 - 203 mm)
max.
6
48.125 in.
(1222 mm)
59.625 in.
(1514 mm)
65.125 in.
(1654 mm)
65.125 in.
(1654 mm)
72 in.
(1829 mm)
74.25 in.
(1886 mm)
1
2
3
4 6
LENGTH FOR ONE MACHINE
COMPACTED FILL DIRT 18 in. (457 mm) DEPTH
3
3 3 5
Brush with
Cement Grout
Brush with
Cement Grout
Brush with
Cement Grout
COMPACTED FILL DIRT 18 in. (457 mm) DEPTH
