Specifications and Dimensions
F8138601 10
Machine Dimensions
Dimensional Clearances
Allow a minimum of 24 inches (60 cm) at the rear and
6 inches (15.24 cm) at the sides for maintenance,
inspection, and adjustment. Allow at least 6 inches
(15.24 cm) between machines in multiple installations.
NOTE: The dimensions shown here are for
planning purposes only. They are approximate and
subject to normal manufacturing tolerances. If
exact dimensions are required for construction
purposes, contact the distributor or the
manufacturer. We reserve the right to make
changes at any time without notice.
UWTV Models
Crush hazard.
To avoid personal injury and/or property
damage, do not tip the UW150 machine
more than 25 degrees in any direction.
W642
WARNING
(Refer to Figure 3 and Figure 4)
Dim
ension
35 60 80 100 125 150
in mm in mm in mm in mm in mm in mm
A 30.125 765 35.625 905 41.125 1045 41.125 1045 48 1219 50.25 1277
B
1 33.375 848 36.625 930 41.5 1054 41.5 1054 48 1219 50.25 1277
C
23.75 603 28.25 718 29 737 29 737 29 737 32 813
D 43.625 1108 45 1143 51.5 1308 54.5 1384 58 1473 63 1600
E
2 .5 13 1 25 3 76 3 76 1.5 38 2.9 73
F 55.5 1410 64.5 1638 68.5 1740 68.5 1740 72 1829 79 2007
G 2 36 914 36 914 43.75 1111 43.75 1111 48 1219 56 1422
H 8 203 15.5 394 16.875 429 16.875 429 11.375 289 15.75 400
J 43.14 1096 49.8 1265 53.54 1360 53.54 1360 56.4 1433 62.85 1596
K 46.64 1185 53.3 1354 57.04 1449 57.04 1449 59.9 1521 66.35 1685
L 5.12 130 5.12 130.05 7.12 181 7.12 181 7.12 181 7.12 181
M 2.62 66 2.62 66 3.62 92 3.62 92 3.62 92 3.62 92
N 1.37 35 1.37 35 2.25 57 2.25 57 2.25 57 2.25 57
O 3.87 98 3.87 98 5 127 5 127 5 127 5 127
P 2.5 64 2.5 64 2.75 70 2.75 70 2.75 70 2.75 70
Q 2.5 64 2.5 64 3.5 89 3.5 89 3.5 89 3.5 89
1 Overhang dimensions for the optional starch dispenser are as follows:UW35TV, 3.88 inches (9.86 cm); UW60TV, 1.75 inches
(4.45 cm); UW80TV and UW100TV, 0.33 inch (0.83 cm). (The starch dispenser does not overhang the UW125TV.) (No longer
available.)
2
The overhang dimension for the premium wet clean module option (compatible with wet-clean-capable washer-extractors only) adds
24 inches (60.96 cm) to combined machine dimensions E and G.
Table 1
