Specifications and Dimensions
19 F8138601
NOTE: Mounting holes marked “A” need to be
used on all V-Speed Models only.
Mounting Bolt Hole Locations
Figure 8
PHM630N
26.125 in.
(664 mm)
30.125 in.
(765 mm)
0.75 in.
(19 mm)
2 in.
(51 mm)
36 in.
(914 mm
)
34.
5 in.
(87
6
mm)
28.625 in.
(727 mm)
30
.18
75 in.
(7
67 mm
)
34.16 in.
(868 mm)
40.1875 in.
(1022 mm)
43.28 in.
(1089 mm)
21.
18
75 in.
(53
8
mm)
2 in.
(51 mm)
35 MODEL
FRONT OF MACHINE
A A
