Specifications and Dimensions
23 F8138601
PHM778N
Figure 12
PHM778N
47
.8
75 in.
(12
16 mm
)
15 in.
(381 mm)
4 in.
(102 mm)
56 in.
(142
2 m
m
)
10.375 in.
(264 mm)
150 MODEL
FRONT OF MACHINE
10.375 in.
(264 mm)
57.4 in.
(1457 mm)
51.375 in.
(1305 mm)
48.125 in.
(1223 mm)
47 in.
(1193 mm)
12.125 in.
(308 mm)
50 in.
(1270 mm)
1.5 in.
(38.1 mm)
1.5 in.
(38.1 mm)
67.1 in.
(1704 mm)
