Specifications and Dimensions
F8138601 16
Floor Load Data
Static and dynamic loads on the floor or foundation are
shown in Table 2.
UWTV Pocket Hardmount Floor Load Data
Specifications
Design
Series
35 60 80 100 125 150
Static floor load, lbs (kN) U1 and
greater
1272 (5.66) 1677 (7.45) 2292 (10.2) 2490 (11.1) 3283 (14.6) 3936 (17.5)
Static pressure,
lbs/ft 2
U1 and
greater
169 (8.08) 187 (8.94) 184 (8.79) 199 (9.6) 205 (9.8) 202 (9.7)
Dynamic floor load, lbs (kN) U1 and
greater
1648 (7.33) 2824 (12.6) 3679 (16.36) 3690 (16.41) 5011 (22.29) 4358 (19.4)
Dynamic pressure,
lbs/ft 2 (kN/m 2 )
U1 and
greater
219 (10.5) 317 (15.2) 295 (14.2) 295 (14.2) 312 (15) 224 (11)
Dynamic load frequency, Hz U1 and
greater
15 13.6 12.8 12.8 9.7 11.7
1 Maximum vertical load,
lbs (kN)
U1 and
greater
2719 (12.1) 4168 (18.5) 5482 (24.38) 5561 (24.73) 7559 (33.62) 7508 (33.4)
2 Minimum vertical load,
lbs (kN)
U1 and
greater
576 (2.56) 1450 (6.45) 1852 (8.24) 1794 (8.0) 2434 (10.8) 1208 (5.4)
Base moment, lb/ft (kN/m) U1 and
greater
4249 (5.8) 8895 (12.1) 11951 (16.2) 11984 (16.3) 16606 (22.5) 16707 (22.7)
1 Acting in the downward direction against the floor.
2 Acting in the upward direction away from the floor.
Table 2
