Aastra Telecom SIP 57I - Manual (Page 427)

Operational Features
41-001160-00, Release 2.1, Rev 04 5-217
Configuring Operational Features
Operational IP Phone Features
Aastra Web UI
For the 53i:
1 Click on Operation->Programmable Keys.
53i Screen
2 On the 53i, select a key from keys 1 through 6.
3 In the "Type" field, select XML from the list box.
4 On the 53i, in the "Label" field, enter a label that displays on the IP phone for the XML softkey. For
example, "aastra".
5 In the "Value" field, enter the URI that the phone performs a GET on when the key is pressed. For
example:
http://10.50.10.140/script.pl?name=$$SIPUSERNAME$$
Note: You can use the following variables in the URI:
•
$$SIPUSERNAME$$
• $$SIPAUTHNAME$$
• $$PROXYURL$$
• $$REMOTENUMBER$$
• $$DISPLAYNAME$$
• $$INCOMINGNAME$$
6 Click to save your changes.
