48
** The 2D code below is supported by MW-145BT and MW-260.
ESC i D Print DataMatrix code**
[ASCII] ESC i D or d [Parameters] [2D code data] \\\
[Decimal] 27 105 68 or 100 [Parameters] [2D code data] 92 92 92
[Hexadecimal] 1B 69 44 or 64 [Parameters] [2D code data] 5C 5C 5C
[Parameters]
All parameters must be set in the correct order. If irregular parameters are detected, default values will
automatically be used.
１ . Cell size
[Decimal 1 byte] 3
[Decimal 1 byte] 4
[Decimal 1 byte] 5
[Decimal 1 byte] 6
[Decimal 1 byte] 8
[Decimal 1 byte] 10 Setting a dot size on each cell
Printing a 3 dots x 3 dots sized cell (Default value)
Printing a 4 dots x 4 dots sized cell.
Printing a 5 dots x 5 dots sized cell.
Printing a 6 dots x 6 dots sized cell.
Printing an 8 dots x 8 dots sized cell.
Printing a 10 dots x 10 dots sized cell.
2. Symbol type
[Decimal 1 byte] 0
[Decimal 1 byte] 1
ECC200 Square (Default value)
ECC200 Rectangle
3. Height size
[Decimal 1 byte] 0
[Decimal 1 byte] 10
[Decimal 1 byte] 12
[Decimal 1 byte] 14
[Decimal 1 byte] 16
[Decimal 1 byte] 18
[Decimal 1 byte] 20
[Decimal 1 byte] 22
[Decimal 1 byte] 24
[Decimal 1 byte] 26
[Decimal 1 byte] 32
[Decimal 1 byte] 36
[Decimal 1 byte] 40
[Decimal 1 byte] 44
[Decimal 1 byte] 48
[Decimal 1 byte] 52
[Decimal 1 byte] 64
[Decimal 1 byte] 72
[Decimal 1 byte] 80
[Decimal 1 byte] 88
[Decimal 1 byte] 96
[Decimal 1 byte] 104
[Decimal 1 byte] 120
[Decimal 1 byte] 132
[Decimal 1 byte] 144
[Decimal 1 byte] 0
[Decimal 1 byte] 8
[Decimal 1 byte] 12
[Decimal 1 byte] 16
-ECC200 Square:
Height count of cells Automatically (Default value)
Height count of 10 cells
Height count of 12 cells
Height count of 14 cells
Height count of 16 cells
Height count of 18 cells
Height count of 20 cells
Height count of 22 cells
Height count of 24 cells
Height count of 26 cells
Height count of 32 cells
Height count of 36 cells
Height count of 40 cells
Height count of 44 cells
Height count of 48 cells
Height count of 52 cells
Height count of 64 cells
Height count of 72 cells
Height count of 80 cells
Height count of 88 cells
Height count of 96 cells
Height count of 104 cells
Height count of 120 cells
Height count of 132 cells
Height count of 144 cells
- ECC200 Rectangle:
Height count of cells Automatically (Default value)
Height count of 8 cells
Height count of 12 cells
Height count of 16 cells
4. Width size
[Decimal 1byte] X
-ECC200 Square:
Width count of cells equal to height count
