949-1277-3 Page 26 December, 1998
rSPt (Option 924, 926, 928, Analog Remote Set Point) Remote Set Point:
Select On or OFF.
OFF
The control uses the value set for SP1.
On The control uses the value set by the analog remote set
point signal as established by the Secure Menu items
rSCL and rSCH. If the analog signal fails, the control will
display the error message CHEC/ LorE and revert to the
SP1 local value.
LOrE (Option 992, 993, Serial Communications) Local / Remote Status:
Select LOC or rE.
LOC
The host computer is advised not to send remote
commands. Any write commands sent to the controls
will be rejected.
rE The host computer is allowed to send write commands.If
the control is not addressed within the time set in the nAt
(No Activity Timer, see Secure Menu) the CHEC LorE
error message will be displayed.
Addr (Option 992, Serial Communications) Control Address: Set from 1
to 3FF. This number (hexadecimal, base 16) must match the
address number used by the host computer. Viewed only in this
menu. To change this parameter, see Addr in the Secure Menu.
SECURE MENU
Hold UP ARROW & ENTER for 5 Seconds. Press INDEX to advance to the
next menu item. Press UP ARROW or DOWN ARROW to change the value
in the display. Press ENTER to retain the value.
OUTPUTS ARE DISABLED (TURNED OFF) WHILE CONTROL IS IN
SECURE MENU.
SECr Security Code: See the Security Level Selection and the Password
Table in this manual, in order to enter the correct password.
InP Input Type: Select one of the following. Refer to the Input wiring
section for the proper wiring.
J-IC Type “J” Thermocouple
CA Type “K” Thermocouple
E- Type “E” Thermocouple
t- Type “T” Thermocouple
L- Type “L” Thermocouple
n- Type “N” Thermocouple
r-13 Type “R” Thermocouple
S-10 Type “S” Thermocouple
b- Type “B” Thermocouple
