December, 1998 Page 19 949-1277-3
SECONDARY MENU
Hold UP ARROW & ENTER. Press INDEX to advance to the next menu
item. Press UP ARROW or DOWN ARROW to change the value in the
display. Press ENTER to retain the value.
A1Lo Alarm 1 Low: The Low Alarm point is usually set below the Set
Point. May not appear depending on AL1 setting in Secure Menu.
A1Hi Alarm High: The High Alarm Point is usually set above the Set
Point. May not appear depending on AL1 setting in Secure Menu.
A2Lo Alarm 2 Low: The Low Alarm point is usually set below the Set
Point. May not appear depending on AL2 setting in Secure Menu.
A2Hi Alarm 2 High: The High Alarm Point is usually set above the Set
Point. May not appear depending on AL2 setting in Secure Menu.
Out1 Output selection: Select OnOf, 1tP, 1PuL, or ProP.
ONOF
A setting of ONOF allows the control to operate as a
simple on/off mode. This setting forces the control to
turn off at set point, and on at the set point plus the
differential (SP_d). When selected, the Out1/OnOF
menu item is followed by ####/SP1d, and the tunE, Pb,
rES, OFS, rtE, and ArUP selections in the Secondary
menu and the S1OL and S1OH selections in the Secure
menu are suppressed.
SP_d Set Point On-Off Differential (hysteresis). Se-
lect 1 to 9999 (direct acting), or -1 to -9999
(reverse acting). This value will be negative for
reverse acting set points, and positive for direct
acting outputs. Set the value for the amount of
difference between the turn off point (set point)
and the turn on point. The following drawing
shows output behavior for reverse and direct
action.
##tP Time Proportioning Cycle Time. Select 1tP to 80tP.
1tP A setting of 1tP is recommended for solid state
outputs (SSR or 15VDC).
2tP to 80tP Time Proportioning Control is adjustable in
1 second steps. Recommended for mechanical
outputs (relays, solenoids, etc.). For best con-
tact life, a time should be selected as long as
possible without causing the process to wan-
der.
#PuL Pulsed Time Proportioning Output: Select 1PuL
