3.1.2 - DPW without RTD option Process Information Screens
Pressing UP and DN buttons from initial PI screen will switch display as following:
[Initial PI screen]
Action: Keypad UP
i
Figure 3.10: DPW Without RTD option PI Screen with Main and Pilot Totalizer
Action: Keypad UP
i
Figure 3.11: DPW Without RTD Option Initial PI Screen with
Main and Pilot Totalizer
Action: Keypad UP
i
Figure 3.12: DPW Without RTD Option Initial PI Screen
With Flow Rate and Main Totalizer
3.2 Menu Sequence
The listing below gives a general overview of the standard top-level display menu
sequence when running firmware version A002. The ESC pushbutton is used to
toggle between the process mode (PI screens) and the menu.
The listing in Section 3.2 shows the standard display menu sequence and
submenus using the UP button to move through the menu items. The first message
displayed the first time the ESC button is pressed after the converter is powered up
is "Prog. Protection ON". Thereafter, pressing the ESC button while the flow meter
is in monitoring mode (PI screens) will display the parameter that was last exited.
Program Protection may be turned "off" by pressing the ENT button when the Prog.
Protection menu is displayed. The firmware will prompt with "Change Prog Prot”.
Pressing UP or DN button will toggle current protection status. If password is set to
any value more than zero, the firmware will prompt with "Enter Prot Code". User
has to enter up to 3 digits program protection code, in order to be able to access
password protected menus. Once correct password is entered, program protection
id turned off until unit is powered up again.
When the last menu item is reached, the firmware "wraps around" and scrolls to the
first item on the menu once again (see Figure 3.12). The menu items in the first
column are upper-level configuration mode functions. Submenu selections (shown
indented in the second column) only appear if the associated upper level is
selected by pressing the ENT push button. The allowable selections of sub-menu
items which are selected by tabular means are shown in detail in Section 3.3.
5.001 Gl/min AD
PT: 65.81 Gal
MT: 60639.38 Gal
PT: 65.81 Gal
5.001 Gl/min AD
MT: 60639.38 Gal
Prog. Protection on/off
Prog. Prot. Code old/new
Submenu Flow Meter Info
Submenu Measuring Units
Submenu Flow Alarm
Submenu Temp. Alarm
Submenu Main Totalizer
Submenu Pilot Totalizer
Submenu Optical Outputs
Submenu FlowMeter Config
LCD Back Light 50% FS
Submenu Alarm Events Log
Submenu Diagnostic
Configuration Data
Figure 3.12 Upper Level Menu Structure
