Dwyer DPW - Manual (Page 24)

No.
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
Indication
FlowTbl[6].FlowPFS
FlowTbl[6].LinCounts
FlowTbl[7].FlowPFS
FlowTbl[7].LinCounts
FlowTbl[8].FlowPFS
FlowTbl[8].LinCounts
FlowTbl[9].FlowPFS
FlowTbl[9].LinCounts
FlowTbl[10].FlowPFS
FlowTbl[10].LinCounts
T_InScale
T_InOffset
T_Mode
DiagEventMask
FlowLinearizer
T_AlarmMode
T_AlarmDelay
T_AlarmLatch
T_LowAlarm_C
T_HiAlarm_C
ReservedF3
FluidName[20]
CalibratedBy[20]
CalibratedAt[20]
DateCalibrated[12]
DateCalibrationDue[12]
UserTagName
EEMagicNumber
Data Type
float
uint
float
uint
float
uint
float
uint
float
uint
float
float
float
uint
uint
uint
uint
uint
float
float
float
char[20]
char[20]
char[20]
char[12]
char[12]
char[12]
uint
Notes
Flow Linearizer Index 6 PFS [0.0 – 1.0]
Flow Linearizer Index 6 Counts
Flow Linearizer Index 7 PFS [0.0 – 1.0]
Flow Linearizer Index 7 Counts
Flow Linearizer Index 8 PFS [0.0 – 1.0]
Flow Linearizer Index 8 Counts
Flow Linearizer Index 9 PFS [0.0 – 1.0]
Flow Linearizer Index 9 Counts
Flow Linearizer Index 10 PFS [0.0 – 1.0]
Flow Linearizer Index 10 Counts
Temperature RTD input Scale**
Temperature RTD input Offset**
Reserved**
Mask for Diagnostic Events: Clear bit-> mask corresponding event.
Default mask is 0xFFFFh
Flow Linearizer (0-Disabled, 1-Enabled)
Temp. Alarm Mode (0=Disabled, 1=Enabled)**
Delay in seconds 0-3600 for Tem.Alarm action**
Temp Alarm Latch
0-3**
Low Temperature Alarm in %FS [-.1-1]**
High Temperature Alarm in %FS [-.1-1]**
Reserved
Name of the Liquid used for Calibration
Name of person, meter was calibrated by
Name of the Calibration Lab
Calibration date
Date calibration due
User Defined Device Tag Name or Number
Number used to verify EEPROM integrity
** Not supported in some hardware configurations
APPENDIX II
Component Diagram Top Side
Component Diagram Bottom Side
Page 24
