Valid for single and double acting
Configuration of 0 and 100% Request Action
Linear
Left
Linear
Right
Rot
cclockw
Rot
clockwise
Direct Reverse
4 mA = 0%
20 mA = 100%
4 mA = 100%
20 mA = 0%
4 mA = 0%
20 mA = 100%
4 mA = 100%
20 mA = 0%
4 mA = 0%
20 mA = 100%
4 mA = 100%
20 mA = 0%
4 mA = 0%
20 mA = 100%
4 mA = 100%
20 mA = 0%
Configuration requested
MENU 1:
"Mounting"
MENU 3:
"Valve Action"
1.1 1.2 1.3 1.4 3.1 3.2
Operation
