Page 86: Electrical data – x2c0 continued
SmartCool
TM
- D
Precision Air Conditioning
86
Precision Air Conditioning
Installation, Maintenance and Commissioning Manual :6877419 02/2013
Electrical Data – X2C0 Continued
SC25D045-X2C0-0
SC25D050-X2C0-0
SC25D055-X2C0-0
Standard Condenser Match
1 x CR65
1 x CR65
1 x CR80
Unit Data - X2C0
Nominal Run Amps
A
64.8
64.4
82.2
Maximum Start Amps
A
151.6
143.6
175.9
Recommended Mains Fuse Size
A
80
100
100
Max Mains Incoming Cable Size
mm²
35
35
35
Mains Supply
V
400V / 3PH + N / 50Hz
Control circuit
VAC
24
24
24
Unit Data Cooling Only X2C0
Nominal Run Amps
A
47.8
47.5
54.2
Maximum Start Amps
A
134.5
126.6
167.2
Recommended Mains Fuse Size
A
63
63
63
Evaporator Fan Motor - Per Fan
Motor Type
AC
AC
AC
Quantity x Motor Size
kW
3 x 2.38
3 x 2.38
3 x 2.38
Full Load Amps
A
5
5
5
Locked Rotor Amps
A
17.5
17.5
17.5
Compressor 1 , Circuit 1
Motor Size
kW
6.31
7.19
7.19
Nominal Run Amps
A
13.27
12.87
12.87
Locked Rotor Amps
A
100
92
92
Type of Start
Direct On Line
Compressor 2, Circuit 1
Motor Size
kW
6.31
7.19
9.46
Nominal Run Amps
A
13.27
12.87
16.93
Locked Rotor Amps
A
100
92
130
Type of Start
Direct On Line
Standard Condenser Match - AC Motor Per Fan
Quantity x Motor Size
kW
2 x 0.6
2 x 0.6
3 x 0.6
Full Load Amps
A
2.62
2.62
2.62
OPTIONAL EXTRAS
Electric Heating
Number of stage of Reheat
2
2
3
Number of Elements
6
6
9
Rating (Total)
kW
21
21
31.5
Current Per Phase
A
30.31
30.31
45.47
Humidifier
Capacity
kg/hr
8
8
8
Rating
kW
6
6
6
Full Load Amps
A
8.67
8.67
8.67
First upgrade Fan Motor - EC Motor - Per
Fan
Quantity x Motor Size
kW
2 x 2.2
2 x 2.2
3 x 2.2
Full Load Amps
A
3.3
3.3
3.3
Locked Rotor Amps
A
3.3
3.3
3.3
Second upgrade Motor - EC Motor - Per Fan
Quantity x Motor Size
kW
2 x 3.1
2 x 3.1
3 x 3.1
Full Load Amps
A
4.8
4.8
4.8
Locked Rotor Amps
A
4.8
4.8
4.8
Standard Condenser Match - EC Motor-Per Fan
Quantity x Motor Size
kW
2 x 0.73
2 x 0.73
3 x 0.73
Full Load Amps
A
3.3
3.3
3.3
Condenser Match - SCAF Fan
Quantity x Motor Size
kW
2 x 1.4
2 x 1.4
3 x 1.4
Full Load Amps
A
6
6
6
(1) Values given for function units with standard selections for heating, humidification, supply air fans and matched condenser
at 7°C evaporating and 54.4°C condensing
(2) Stated motor power is based on maximum electrical power absorbed
(3) Values are per compressor
